The machine achieves sewing speed of 3,200sti/min. The machine's starting, stopping, thread-trimming and automatic presser
lifting speeds have been increased to significantly shorten total cycle time.
| Model |
Application |
Max.sewing speed |
Max.sewing Aree |
Stitch Length |
Lift Of The Work Clamp |
Hook |
Number Of Stitches |
Number Of Standard Patterns |
Number Of Date That Can Be Input |
Needle |
Package Size |
Weight |
| DY-430D-SS |
Standard |
3,200sti/min |
30(L)×40(W)mm |
0.1mm~10mm
(0.1mmstep) |
Standard 14mm (17mm when the reverse-rotation needle-up function) |
Standard shuttle hook |
Max.20,000 stitches |
50 patterns |
200 patteerns(for up to 150 patterns,sewing data can be added.) |
DP×5（#14） |
71×45×55cm |
75/64kg |
| DY-430D-HS |
Heavy-weight |
3,200sti/min |
30(L)×40(W)mm |
0.1mm~10mm
(0.1mmstep) |
DP×17（#21） |
71×45×55cm |
75/64kg |
| DY-430D-FSLF |
Foundation |
3,200sti/min |
30(L)×40(W)mm |
0.1mm~10mm
(0.1mmstep) |
DP×5（#11） |
71×45×55cm |
75/64kg |
| DY-430D-MS |
Knits And Knitted Materials |
3,200sti/min |
30(L)×40(W)mm |
0.1mm~10mm
(0.1mmstep) |
DP×5（#11） |
71×45×55cm |
75/64kg |
|
