Products Summary
The model is based on DY-20688D series, enlarged working space 760mm, available for sewing large working space furnitures, car interior decoration, tents umbrellas, etc;
| Model Model |
DY-20688L-1D3 |
DY-20688L-2D3 |
| Max sewing sewing speed |
2400r.p.m |
| Stitch length |
Standard 0-9mm， Special 12mm |
| Needle Needle bar bar stroke |
34mm |
| Presser Presser foot lift foot lift |
By hand/pneumatic9/20mm |
| Needle Needle size |
DP×17 18#-23# |
| Needle gauge |
/ |
Standard 6.4mm; Special 3.2/4.8/8/9.5/12.7mm |
| Presser Presser foot alternation |
1-7mm |
| Auto Presser Presser foot lift foot lifter |
Pneumatic |
| Presser Presser alternation adjuster |
Pneumatic |
| Safety clutch device |
√ |
| Lubrication |
Auto lubricated |
| Working space |
760×120mm |
| Motor |
220V/750W Servo motor |
|
