Products Summary
The series is designed with top and bottom feeding mechanism, it avoids displacement between layers efficiency and the large amount alternating presser foot make it possible to sew heavy duty materials; It is available for performing lap seams and decorative seams on jeans, heavy sports wears, sports apparatus, safely airbags, etc with neat, firm and elastic stitches;
Model |
Max sewing speed |
Stitch length |
Presser foot lift |
Take-up lever |
Needle size |
Lubrication |
Needle gauge |
Servo motor |
DY-0318K-1D3 |
2500r.p.m. |
1.4-8mm |
6/13mm |
Needle bar type |
TV×5 18#-23# |
Auto lubricated |
|
220V/550W |
DY-0318K-2D2 |
Standard 6.4mm
special 8/9.5/12.7mm |
DY-0318K-3D2 |
3.2-3.2mm |
|
