Products Summary
This series is designed with edge cutter on base of DY-0318-1D4 series, enables sewing and edge-cutting easier at the same time;The thickness to be cut can be up to 7mm; The standard width to be cut is 4.8mm and the special size of 3.2 /6.4 /8mm must be specified when ordering;
Model |
Max sewing speed |
Stitch length |
Needle bar stroke |
Presser foot lift |
Needle size |
Feed dog |
Lubrication |
Servo motor |
DY-0318-1D4C |
2000r.p.m |
0-8mm |
35mm |
6/13mm |
DP×17 18#-24# |
3 Rows of teech |
Auto lubricated |
220V/550W |
|
