DY-0318-1D4C
Direct Drive Heavy Duty Top And Bottom Feed Lockstitch Sewing Machine With Edge Cutter And Auto Thread Trimmer

Products Summary

This series is designed with edge cutter on base of DY-0318-1D4 series, enables sewing and edge-cutting easier at the same time;The thickness to be cut can be up to 7mm; The standard width to be cut is 4.8mm and the special size of 3.2 /6.4 /8mm must be specified when ordering;

Model Max sewing speed Stitch length Needle bar stroke Presser foot lift Needle size Feed dog Lubrication Servo motor
DY-0318-1D4C 2000r.p.m 0-8mm 35mm 6/13mm DP×17 18#-24# 3 Rows of teech Auto lubricated 220V/550W
